Avaya IP500 Digital Station 30B (700501586)
The IP500 Digital Station 30B is an expansion module that will provide users an additional 30 digital station ports for the Avaya IP Office System. These digital ports can be either Nortel or Avaya digital phones, however, they can not be mixed simultaneously. If you are using IP Office 9.0 or higher, the digital station ports can be used as DS or TCM ports.
- Digital station ports: 30 RJ45
- Support of either DS ports or TCM ports but not both simultaneously
- Free-standing module - can be stacked on or under other IP office modules
- Wall or rack-mountable
- Includes Atlas 1-Year Warranty with Extended Warranty options available!
- On IP Office 8.1, the Avaya Digital Station 30B only supports DS ports - IP500 16B/30B Patch Bulletin
- On IP Office 9.0 or higher, both DS ports and TCM ports are supported but cannot be used at the same time
- DS ports support Avaya 1400, 2400, 5400, and 9500 series telephones
- TCM ports support Avaya/Nortel M7000 and T7000 series telephones
IP500 External Expansion Module
Power supply and power cord
Blue expansion interconnect cable
